Medical Celling Mounted LED Shadowless Surgical Operating Light

1. II LED surgical operating light using Germany imported Osram LED medical light source, II LED Touch pad control system is developed for adjustment control of power switch, brightness switch, illumination level, color temperature, color rendering index, to meet medical personnel requirement of variant operation.

2. High Luminance with optimum color rendering
Designed to provide a led light output with a color rendering index and color temperature which is very close to natural daylight.This helps the surgeon to distinguish between pathological and healthy tissue.

3. Optimum design for clean air ceilings (Laminar Air Flow)
The perfect design for LED Operating light reduce the airflow surface beneath the ventilated ceiling, Flow- optimized light head and reduced surface temperature minimise turbulence in laminar air flow.

  • II LED 700 500 Surgical Operating Light

  • BEDFORDMED

  • 9405429000

Availability:

Medical Celling Mounted LED Shadowless Surgical Operating Light


II LED 700 500 Operating Light Features:


1. II  LED surgical operating light using Germany imported Osram LED medical light source, II LED Touch pad control system is developed for adjustment control of power switch, brightness switch, illumination level, color temperature, color rendering index, to meet medical personnel requirement of variant operation.

2. High Luminance with optimum color rendering
Designed to provide a led light output with a color rendering index and color temperature which is very close to natural daylight.This helps the surgeon to distinguish between pathological and healthy tissue.

3. Optimum design for clean air ceilings (Laminar Air Flow)
The perfect design for LED Operating light reduce the airflow surface beneath the ventilated ceiling, Flow- optimized light head and reduced surface temperature minimise turbulence in laminar air flow.


Configuration for II LED 700/500 Germany Square Arm LED Surgical Lamp:

One 700 led light head with two sterilizer handling

one 500 led light head with two sterilizer handling

Two Germany Imported Balance Square Arm

One set light base with two rotating Arm.


Specification for II LED 700 500 Surgical Operating Lamp:

Technical specifications II LED 700   II LED 500
Central illuminance at 1m working distance 40, 000~180,000 lux 40, 000~160,000 lux
Focusable light-field size at 1 m distance 120~300mm 120~300mm
Colour temperature 3500~5000K 3500~5000K
Depth of Focus >700mm >700mm
Colour Index Ra 95 95
Power Supply 110~240V 50/60Hz 110~240V 50/60Hz
Effective bulb service life >50, 000h >50, 000h
Diameter of lamp housing 700mm 500mm
Power consumption (W) 80 48
Lamp Head LED bulbs Qty 80 48
Installation height (Ceiling type) 280-320 cm 280-320 cm

亮度 700x500



Frequently Asked Questions:


Q1: Are you trading company or manufacturer?

A: We are Manufacturer for Operating Lamp and Operating Table.


Q2: What is your terms of payment?

A: We accept TT/LC/West Union.


Q3:Do you offer guarantee for the products?

A: Yes, we offer 1 years warranty to our operating lamp.


Q4: How long is your delivery time?

A: Generally, it is 20~30 days after deposit received and all purchase details confirmed. It will be 5-7days if products are in stock.
